Bunn U3 Illustrated Parts Catalog

ITEM PART NO. QTY. DESCRIPTION
37
ELECTRICAL CONTROLS AND INDICATOR LIGHTS
1 01260.0000 1 Circuit Breaker, 15 Amp (Includes nut)(120/208V, 120/240 Brewers)
2 03231.0000 1 Fuse Holder (Includes cap & nut)(240V Brewers)
3 03230.0001 1 Fuse, MDL- 5 Amp 250V
4 00908.0000 2 Nut, Hex #8-32
5 20203.0100 1 Lockwasher, Internal Tooth #8
6 07048.1000 1 Probe Kit, Liquid Level
07246.1000 1 Probe Kit, Liquid Level (Marine Applications)
01315.0000 2 Screw, Truss Head #8-32 x .375”
7 07070.0000 1 Bushing, Snap .687 Dia Mounting Hole
8 07014.0000 1 Terminal Housing
9 01061.0000 1 Switch,Momentary Start (120/208, 120/240V, 380V, 440V Brewers & 240V Brewers
prior to #U300004095)
10 12984.0006 1 Lamp Assembly 120V (Brewers W/Brew Lockout)
12984.0007 1 Lamp Assembly 240V (Brewers W/Brew Lockout)
11 07104.0000 1 Lamp Assembly, Indicator - Power On 120V
07104.0004 1 Lamp Assembly, Indicator - Power On 240V (Brewers prior to #U300004095)
12 07183.0000 1 Switch, Half Batch Selector (120/208V, 120/240V, 380V, 440V Brewers & 240V
Brewers prior to #U300004095)
13 04225.0002 1 Switch, ON/OFF 120V & 240V - Black (120/208V, 120/240V, 380V, 440V Brewers &
240V Brewers prior to #U300004095)
14 00718.0000 1 Bushing, Snap 1.125” Dia Mounting Hole
15 - - - - - - - - - Timer, 5 Min 120V (Early Models - Order Item 40)
- - - - - - - - - Timer, 5 Min 240V (Early Models - Order Item 41)
- - - - - - - - - Timer, 10 Min 120V (Early Models - Order Item 40)
- - - - - - - - - Timer, 10 Min 240V (Early Models - Order Item 41)
32400.0002 1 Digital Timer - 120V (Late Models)
32400.0003 1 Digital Timer - 240V (Late Models)
01315.0000 2 Screw, Truss Head #8-32 x .375” (Early Models)
01320.0000 2 Screw, Round Head #8-32 x 1.00’ (Late Models)
12919.0008 1 Cap, Terminal (Not illustrated)
16 07241.0000 1 Bracket, Contactor Mounting (120/208V, 120/240V, 380V, 440V Brewers & 240V
Brewers prior to #U300004095)
01315.0000 1 Screw, Truss Head #8-32 x .375”
17 07105.0000 1 Shield, Protective
01327.0000 1 Screw, Pan Head #10-32 x .375”
01522.0000 1 Washer, Flat .203” I.D. x .50” O.D.
18 06335.1000 1 Contactor Assembly, 120V
06335.1002 1 Contactor Assembly, 240V (Brewers prior to #U300004095) (Incl. Item 39)
01315.0000 2 Screw, Truss Head #8-32 x .375”
00912.0000 2 Fastener, “J” Type #8
19 07074.1000 1 Level Control Board, 5 Sec 120V
07074.1009 1 Level Control Board, 5 Sec 240V
01327.0000 1 Screw, Pan Head #10-32 x .375”
01512.0000 1 Lockwasher, Internal Tooth #10
(Continued)
28046 070102
Includes items 4, 5, 27
& hardware indented below
