Bunn U3 Illustrated Parts Catalog

ITEM PART NO. QTY. DESCRIPTION
5
HOUSING, PANELS AND COVERS
*Single Service (Front Faucets Only)
**Double Service (Front and Rear Faucets)
***Scrambler (Left and Right Side Faucets)
ITEM PART NO. QUANTITY DESCRIPTION
* ** ***
1 07239.0000 1 - 1 Cover, Cupola - Rear
07240.0000 - 1 - Cover, Cupola - Rear
01317.0000 2 2 2 Screw, Truss Head #8-32 x .5”
2 28064.1000 1 1 1 Housing, Cupola (120/208 and 120/240V Models)
28064.1001 1 1 1 Housing, Cupola (208 or 240V Models)
28064.1002 1 1 1 Housing, Cupola (380 or 440V four wire Models)
28064.1003 1 1 1 Housing, Cupola (380V three wire Models)
3 07238.0000 1 1 1 Bracket, Switch Mounting (I20/208V, 120/240V, 380V, 440V Brewers & 240V
Brewers Prior to #U300004095)
27903.0000 1 1 - Bracket, Switch Mounting (240V Brewer #U300004095 and up)
01315.0000 2 2 2 Screw, Truss Head Phillips #8-32 x .38”
4 07236.0000 1 1 1 Cover, Cupola - Front (Brewers W/Out Brew Lockout)
07236.0001 1 1 1 Cover, Cupola - Front (Brewers W/Brew Lockout)
07236.0002 1 1 1 Cover, Cupola - Front (Brewers W/External Thermostat Control)
02322.0000 2 2 2 Screw, Truss Head. Blk Oxide #8-32 x .50”
00917.0000 2 2 2 Fastener, “J” Type #8-32
5 07248.0000 1 1 1 Decal, Power/Half-Full/Start
6 00878.0000 1 1 1 Decal, Turn Off When Unattended
7 21667.0000 1 1 1 Decal, Control (Brewers W/External Thermostat Control)
8 00823.0000 1 1 1 Decal, BUNN-O-MATIC (Brewers W & W/Out Brew Lockout)(Prior to 10/1/99)
21667.0002 1 1 1 Decal, BUNN-O-MATIC (Brewers W & W/Out Brew Lockout)(Effective 10/1/99)
9 07226.0000 1 1 1 Panel Assy, 120/208V and 120/240V Brewers
07226.0002 1 1 1 Panel Assy, 208V, 230V, 240V, 380V and 440V Brewers
01315.0000 12 12 12 Screw, Truss Head Phillips #8-32 x .38”
10 07288.0000 4 4 4 Gasket, Reservoir Mounting
11 07289.0001 2 2 2 Gasket, Panel Mounting - 7.72” LG
12 07289.0002 2 2 2 Gasket, Panel Mounting - 13.25” LG
13 07001.1000 1 - - Housing W/Decals (Std. - W/4” Adjustable Legs)
07001.1002 1 - - Housing W/Decals (Opt. - W/8” Adjustable Legs)
07122.1000 - - 1 Housing W/Decals (W/4” Adjustable Legs)
07002.1000 - 1 - Housing W/Decals (W/4” Adjustable Legs)(Includes items 16,17,26 & 31)
14 00831.0000 1 1 1 Decal, Warning - Electrical
15 00656.0000 1 1 1 Decal, Comply to Plumbing Code
16 29299.0000 2 2 2 Decal, Caution Swing Spout
17 10044.0000 1 1 1 Decal, Warning Shut Off Power
(Continued)
Includes items
14 -17,26 & 31
Each Includes
item 28
28046 080906
Also Order
Item 32
