Bunn U3 Illustrated Parts Catalog

ITEM PART NO. QTY. DESCRIPTION
9
FUNNELS, SPRAYHEADS, FILTER BASKETS AND SUPPORTS
1 00725.0000 2 Knob, Plastic - Black
01315.0000 2 Screw, Truss Head Phillips #8-32 x .38”
2 01192.0000 2 Cover
3 07023.0003 2 Cover Assy, Plastic - Black (Includes items 4 & 5)
07023.0002 1 Cover Assy, Plastic - Orange (Includes items 4 & 5)
07177.0003 2 Cover Assy, Plastic - Black (Brewers W/Filter Support)(Includes items 4, 5 & 8)
07177.0002 1 Cover Assy, Plastic - Orange (Brewers W/Filter Support)(Includes items 4, 5 & 8)
20508.0001 2 Cover Assy, SST (Includes items 4, 5 & 7)
20508.0003 2 Cover Assy, SST (Brewers W/Filter Support)(Includes items 4, 5, 7 & 8)
4 -------------- 2 Cover, Plastic - Black (Not available. Order item 3)
-------------- 1 Cover, Plastic - Orange (Not available. Order item 3)
-------------- 2 Cover, Plastic - Black (BrewersW/ Filter Support)(Not available. Order item 3)
-------------- 1 Cover, Plastic - Orange (Brewers W/ Filter Support )(Not available. Order item 3)
-------------- 2 Cover, SST (Not available. Order item 3)
-------------- 2 Cover, SST (Brewers W/Filter Support)(Not Available. Order item 3)
5 07024.1002 2 Sprayhead, Plastic - Black (Includes hardware below, except for acorn nuts)
01339.0000 6 Screw, Pan Head #6-32 x .625”
01520.0000 6 Lockwasher, Split #6
00906.0000 6 Nut, Hex #6-32
02319.0000 6 Nut, Acorn #6-32 (Brewers W/SST Funnel Cover)
6 07175.0000 2 Filter Housing Stand (Not used on brewers w/filter support or SST funnels)
7 20507.0001 2 Ring, Funnel Cover, Plastic - Black (Brewers W/SST Funnel Cover)
02328.0004 4 Screw, Pan Head #6-32 x .312”
02319.0000 4 Nut, Acron #6-32
8 07176.0000 2 Basket, Filter Support
9 07022.0012 2 Funnel W/Decals, Plastic - Black (Includes items 16 & 17)
07022.0013 1 Funnel W/Decals, Plastic - Orange (Includes items 16 & 17)
20510.0001 2 Funnel Assy, SST (Includes items 10, 11, 12, 16 & 17)
10 20505.0000 2 Basket, Filter
11 20502.0000 2 Funnel, SST
12 21472.0000 2 Handle, Plastic - Black
01327.0000 4 Screw, Pan Head #10-32 x .38”
13 07021.0002 2 Support, Funnel Plastic - Black (Refer to Item 18)
07021.0004 1 Support, Funnel Plastic - Orange (Refer to Item 18)
-------------- 2 Support, Funnel Plastic - Black (Refer to item 18)(Brewers W/By-Pass. See Swing
Spout and Mounting)
-------------- 1 Support, Funnel Plastic - Orange (Refer to item 18)(Brewers W/BY-Pass. See Swing
Spout and Mounting)
20504 .0000 2 Support, Funnel SST (Refer to Item 18)
-------------- 2 Support, Funnel SST (Refer to item 18)(Brewers W/By-Pass. See Swing Spout and
Mounting)
14 -------------- - Reservoir (See Reservoirs and Faucets)
15 -------------- - Housing (See Housing, Panels and Covers)
(Continued)
Brewers W/Plastic
Funnel Covers
Refer to Item 19
28046 031599
