BURLEY TRAILER OWNER’S INSTRUCTION AND SAFETY MANUAL 9
Attaching the Wheels
First, verify that the tires are infl ated to 30-35 P.S.I. Tip the trailer frame
onto its rear end. With the quick-release lever in the “OPEN” position, insert
the wheel axle assembly completely into the hollow trailer axle, making sure
that the horizontal shaft goes all the way into the axle. Tighten the thumb
nut, so that you feel resistance halfway though tightening the lever. Once the
wheel is fully seated in the hollow axle, position the quick-release lever so
that it is aimed to the rear of the trailer in the “CLOSED” position (the lever
is marked for OPEN or CLOSED positions). Repeat for the other wheel. Note:
wheels are not centered on the axle.
Make sure wheels are held securely, with wheel shaft fully inserted into
the hollow axle. You should not be able to rock or shift wheels. Improp-
erly installed wheels can fall off, causing an accident or serious injury.
WARNING
Quick-release
lever in unlocked
“Open” position
Quick-release
lever in locked
“Closed” position
