The SySTem
Owner‘s Manual 808 MK5
7
(35) TAPE 1 input, L and R, balanced.
(36) TAPE 1 output, L and R, balanced.
(37) Preamplifier OUTPUT 1, L and R, balanced.
(38) Preamplifier OUTPUT 2, L and R, balanced.
(39) REM-OUT 1 output supplies the voltage to remotely switch other Burmester components.
(40) REM-OUT 2 output supplies the voltage to remotely switch other Burmester components.
(41) POWER SUPPLY - terminal for connecting the preamplifier to the power supply.
(42) POWER SUPPLY - terminal for connecting the power supply to the preamplifier.
(43) AC terminal with power switch for connection of the power cord.
(44) Control LED shows the correct functioning of the power supply.
Red: Preamplifier is switched on.
Green: Preamplifier is off. A green LED while the preamplifier has been switched on with the
POWER master switch (1) indicates that the power supply is not working properly.
(45) Proprietary base for acoustically decoupling the preamplifier from external vibration and noise.
For additional insulation effect, we recommend using the supplied carbon fiber damping discs.
