SeTTing Up
Owner‘s Manual 808 MK5
9
S U
1. Carefully remove the preamplifier and the power supply from the packaging and set
both units up in an appropriate location.
2. Make sure the power switch of the AC terminal (43) is set in OFF position.
3. Connect both components with the 14-pin power cord. To do this, plug any of the
two ends of the cord carefully into the POWER SUPPLY terminal (41) of the
preamplifier and screw down the connector.
4. Use the same procedure to connect the other end to the power supply.
5. Connect the other components of your stereo system with the preamplifier.
6. Turn both VOLUME control knobs (6) and (7) to minimum setting (position 1).
7. Connect the power cord with the AC terminal and plug it into the wall outlet.
8. Switch the power switch to ON and toggle the POWER master switch (1) up (on)..
ª The preamplifier is now ready for action.
