KNOCKDOWN BOILER - EQUIPMENT CHECK LIST (Continued)
Component Description
Carton
Designation
on Bar
Code Label
Part
Number
Qty. Req’d. Per Boiler Size
4 Sect. 5 Sect. 6 Sect. 7 Sect. 8 Sect. 9 Sect. 10 Sect. 11 Sect. 12 Sect. 13 Sect. 14 Sect. 15 Sect. 16 Sect. 17 Sect.
18 Sect.
Parts Cartons (Continued)
Heat Exchanger
Insulation Bags
Complete Heat Exchanger
Insulation Wrapper
CPHW 4 101835-04 1
CPHW 5 101835-05 1
CPHW 6 101835-06 1
Front Heat Exchanger
Insulation Wrapper
FTHW 1 101849-01 1
FTHW 2 101849-02 1 1 1 1 1 1 1
FTHW 3 101849-03 1 1 1 1
Rear Heat Exchanger
Insulation Wrapper
RRHW 1 101850-01 1 1 1 1
RRHW 2 101850-02 1 1 1 1 1 1
RRHW 3 101850-03 1 1
Center Heat Exchanger
Insulation Wrapper
CTHW 1 101851-01 1 1 1 1
CTHW 2 101851-02 1 1 1 1 1
Jacket Panel
Cartons
(4 Cartons
Required per
Boiler)
Jacket Common Panels
(Front and Rear)
JC-1 101836-01 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1
Jacket Uncommon Panels
(Outer Top Panels, Tie Bars,
Chaseway Channels &
Internal Wiring Harness)
JC2- 4 101837-04 1
JC2- 5 101837-05 1
JC2- 6 101837-06 1
JC2- 7 101837-07 1
JC2- 8 101837-08 1
JC2- 9 101837-09 1
JC2- 10 101837-10 1
JC2- 11 101837-11 1
JC2- 12 101837-12 1
JC2- 13 101837-13 1
JC2- 14 101837-14 1
JC2- 15 101837-15 1
JC2- 16 101837-16 1
JC2- 17 101837-17 1
JC2- 18 101837-18 1
Jacket Uncommon Top
Panels Cartons
JC3- 4 101838-04 1
JC3- 5 101838-05 1
JC3- 6 101838-06 1
JC3- 7 101838-07 1
JC3- 8 101838-08 1
JC3- 9 101838-09 1
JC3- 10 101838-10 1
JC3- 11 101838-11 1
JC3- 12 101838-12 1
JC3- 13 101838-13 1
JC3- 14 101838-14 1
JC3- 15 101838-15 1
JC3- 16 101838-16 1
JC3- 17 101838-17 1
JC3- 18 101838-18 1
(Continued)
