BOILER
MODEL
BURNER
MIN.
INPUT
(GPH)
BURNER
MAX.
INPUT
(GPH)
BURNER
MODEL
DIFFUSER
OPENING
(IN.)
APPROX. HIGH FIRE
DAMPER SETTING -
TOP / BOTTOM DAMPER
(IN.)
HIGH FIRE
PUMP
PRESSURE
(PSI)
NOZZLE
MAKE
NOZZLE DATA
GPH X ANGLE
- TYPE
MPC4 3.0 3.55 C1-O 3/16 5/16 / Closed 300 Delavan 2.5 X 90 - B
MPC5 3.0 5.5 C1-O 3/8 1 / Closed 300 Delavan 3.5 X 80 - B
MPC6 3.0 7.1 C1-O 1/4 1-3/32 / 1-3/8 270 Delavan 4.5 X 90 - B
MPC7 3.0 8.7 C1-O 1/4 3/4 / 3/4 270 Delavan 6.0 X 90 - B
MPC8 5.5 10.2 C2-OA 1/4 1 / Closed 300 Monarch 6.5 X 80 - PLP
MPC9 5.5 11.8 C2-OA 1/4 13/16 / 11/16 300 Monarch 7.0 X 80 - PLP
MPC10 5.5 13.4 C2-OA 3/16 Both Wide Open 250 Monarch 8.5 X 80 - PLP
MPC11 5.5 15.0 C2-OA 3/8 1-3/8 / 1-1/4 260 Monarch 9.5 X 70 - PLP
MPC12 5.5 16.6 C2-OB 3/8 1-3/4 / 1-3/4 300 Monarch 10.5 X 70 - PLP
MPC13 5.5 18.2 C2-OB 3/8 1-1/2 / 1-1/4 300 Monarch 11.0 X 80 - PLP
MPC14 5.5 19.8 C2-OB 1/2 1-1/4 / 1-1/4 270 Monarch 12.0 X 80 - PLP
MPC15 5.5 21.5 C3-O 1/2 1-7/8 / Closed 280 Hago 14.0 X 80 - BPS
MPC16 7.4 23.0 C3-O 5/16 1-3/4 / 1-3/4 225 Hago 16.0 X 80 - BPS
MPC17 7.4 24.5 C3-O 3/8 2 / 2 280 Hago 15.0 X 80 - BPS
MPC18 7.4 26.0 C3-O 3/8 Both Wide Open 300 Hago 16.0 X 80 - BPS
Table XIVa: Power Flame #2 Oil Burner Specications
BOILER
MODEL
BURNER
MIN.
INPUT
(MBH)
BURNER
MAX.
INPUT
(MBH)
BURNER
MODEL
DIFFUSER
OPENING
(IN.)
APPROX. HIGH FIRE
DAMPER SETTING -
TOP / BOTTOM DAMPER
(IN.)
APPROX. NAT. GAS
MANIFOLD PRESS.
AT ORIFICE TEE
(“WC)
MINIMUM
NAT. GAS
INLET PRESS.
(“WC) **
MPC4 300 500 JR15A-10 N/A 1/2 * 1.2 4.0
MPC5 300 773 JR30A-12 N/A 3/4 * 1.5 4.2
MPC6 300 995 JR30A-12 N/A 13/16 * 2.5 4.9
MPC7 600 1216 JR30A-12 N/A 1-3/32 * 3.5 5.6
MPC8 650 1438 JR50A-15 N/A 3/4 * 2.0 5.9
MPC9 650 1660 JR50A-15 N/A Wide Open * 1.5 6.9
MPC10 650 1881 JR50A-15 N/A 3* 1.8 5.8
MPC11 650 2103 JR50A-15 N/A 2-3/8* 2.1 5.0
MPC4 300 500 C1-G-10 3/16 5/16 / Closed 1.8 4.0
MPC5 300 773 C1-G-10 3/8 1 / Closed 3.8 4.4
MPC6 300 995 C1-G-12 1/4 1-3/32 / 1-3/8 2.4 4.8
MPC7 300 1216 C1-G-12 1/4 3/4 / 3/4 3.5 5.5
MPC8 750 1438 C2-G-15 1/4 1 / Closed 1.0 6.0
MPC9 750 1660 C2-G-15 1/4 13/16 / 11/16 1.4 6.8
MPC10 750 1881 C2-G-20A 3/16 Both Wide Open 2.6 5.9
MPC11 750 2103 C2-G-20A 3/8 1-3/8 / 1-1/4 2.0 6.5
MPC12 750 2325 C2-G-20A 3/8 1-3/4 / 1-3/4 2.4 5.7
MPC13 750 2547 C2-G-20B 3/8 1-1/2 / 1-1/4 2.9 6.5
MPC14 750 2769 C2-G-20B 1/2 1-1/4 / 1-1/4 3.0 6.5
MPC15 900 2991 C3-G-20 1/2 1-7/8 / Closed 1.7 5.6
MPC16 900 3213 C3-G-20 5/16 1-3/4 / 1-3/4 2.3 6.9
MPC17 900 3435 C3-G-20 3/8 2 / 2 2.6 6.6
MPC18 900 3657 C3-G-20 3/8 Both Wide Open 2.5 6.8
* ON “JR” BURNERS, THIS DIMENSION IS THE GAP BETWEEN THE TWO DAMPER BLADES.
** MINIMUM INLET PRESSURE FOR STANDARD UL GAS TRAINS ONLY. CONSULT FACTORY FOR ADDITIONAL INFORMATION.
Table XIVb: Power Flame Gas Burner Specications
