Item
No.
Description
Boiler Sections / Quantity
Part No.
04 05 06 07 08 09 10 11 12 13 14 15 16 17 18
1 MPC-R Rear Section (Machined) 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 100658-01 2 MPC-C Center Section (Machined) 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 100657-01 3 MPC-F Front Section (Machined) 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 100656-01 4 3” Cast Iron Slip Nipple (Machined) 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 7066002 5 7” Cast Iron Slip Nipple (Machined) 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 7066004 6
5/8” Dia. x 86” Lg. Pre-cut Silicone Coated Combustion Chamber Rope Gasket
2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 101635-01
7
5/8” Dia. x 164” Lg. Pre-cut Silicone Coated Perimeter Rope Gasket
3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 101635-03
8 Tie Rods:
8A. 5/8” - 11 x 24-1/4” Lg. 4 4 4 4 101753-01 8B. 5/8” - 11 x 31” Lg. 4 4 4 4 101754-01 8C. 5/8” - 11 x 37-3/4” Lg. 4 4 4 101755-01 8D. 5/8” - 11 x 45-1/2” Lg. 4 4 4 4 101756-01 8E. 5/8” - 11 x 27” Lg. 4 4 4 4 4 8 80861022 8F. 5/8” - 11 x 34” Lg. 4 4 4 4 4 4 4 4 8 4 80861083
9 5/8” - 11 x 2-1/8” Coupling Hex Nut, Plated 4 4 4 4 4 8 8 8 8 8 12 80860455
10 5/8” Flat Washer, USS, Plain 8 8 8 8 8 8 8 8 8 8 8 8 8 8 8 80860608
11 5/8” x 11 Hex Nut, Plain 8 8 8 8 8 8 8 8 8 8 8 8 8 8 8 80860460
12 Tie Rod Tension Spring Assembly 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 101701-01
REPAIR PARTS - CAST IRON SECTION ASSEMBLY
