REPAIR PARTS - COMMON BARE BOILER COMPONENTS
Item
No.
Description
Boiler Sections / Quantity
Part No.
04 05 06 07 08 09 10 11 12 13 14 15 16 17 18
1 4” NPT CI Supply Manifold 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 706MPC401 2 4” NPT CI Return Manifold 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 706MPC402 3
5/8” x 158” Lg. Pre-Cut Silicone Coated Rope Gasket (BSD & Flue Collector)
1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 101635-02
4 Cast Iron Rear Flue Collector, Machined 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 100743-01 5 3/8” Flat Washer, USS, Plated 6 6 6 6 6 6 6 6 6 6 6 6 6 6 6 80860618 6 3/8” -16 x 1-1/4” Lg. Hex Head Cap Screw, Plain 6 6 6 6 6 6 6 6 6 6 6 6 6 6 6 80861309 7 1/4” NPT Square Head Plug, Pipe, Brass 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 806603542 8
Cast Iron Clean-out Cover Assembly (Includes Items 8A & 9)
2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 101667-01
8A Cast Iron Clean-out Cover, Painted 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 101899-01
9
1/2” Dia. x 24-1/2” Lg. Pre-Cut Silicone Coated Rope Gasket, (Clean-out Cover)
2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 101634-01
10 5/16” Flat Washer, USS, Plated 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 80860611
11 5/16” -18 x 7/8” Lg. Hex Head Cap Screw, Plated 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 80861371
12 BSD Hinge/Latch (Machined) 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 100731-01 13 BSD Hinge Loop (Machined) 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 100732-01 14 7/16” Split-Lock Washer, Plated 10 10 10 10 10 10 10 10 10 10 10 10 10 10 10 101758-01 15 7/16” -14 x 1-1/2” Lg. Hex Head Cap Screw, Plated 10 10 10 10 10 10 10 10 10 10 10 10 10 10 10 101759-01 16
Burner Swing Door Assembly (Includes Items 16A, 17 & 18)
1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 100688-01
16A Burner Swing Door, Machined & Painted 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 102647-01
17 Burner Swing Door Insulation (RCF) 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 100691-01 18 Internal BSD Observation Port Gasket (RCF) 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 101518-01 19
Observation Port Components: 19A. 2” NPT x 2-1/2” Lg. Observation Port Nipple 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 8066000101 19B. Sight Glass Fiber Gasket (RCF) 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 8026083 19C. Pyrex Sight Glass 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 8026082 19D. 2” Conduit Bushing Observation Port Cap, Plated 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 806600518
