Burnham MPC - Page 81

81
Item
No.
Description
Boiler Sections / Quantity
Part No.
04 05 06 07 08 09 10 11 12 13 14 15 16 17 18
20 9/16” Split-Lock Washer, Plated 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 101760-01
20A 5/8” Flat Washer 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 80860608
21 9/16” -12 x 2” Lg. Hex Head Cap Screw, Plated 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 101761-01 22 Burner Adapter Plate Cartons (Includes Item 23):
Oil Burner 22A. Beckett (“CF”) BAP No. “00”, 6-3/4” Dia. Hole 1 1 1 1 602263001
22B. Beckett (“CF”) BAP No. “01”, 8-1/4” Dia. Hole 1 1 1 1 1 1 1 1 602263011 22C. Beckett (“CF”) BAP No. “02”, 10-1/4” Dia. Hole 1 1 1 602263021 Gas Burner 22D. Beckett (“CG”) BAP No. “03”, 5” Dia. Hole 1 1 602263031
22E. Beckett (“CG”) BAP No. “04”, 6” Dia. Hole 1 1 602263041 22F. Beckett (“CG”) BAP No. “07”, 7-1/4” Dia. Hole 1 1 1 1 602263071 22G. Beckett (“CG”) BAP No. “08”, 8-1/8”” Dia. Hole 1 1 1 1 1 1 1 602263081
- OR -
Oil, Gas, Gas/Oil Combo Burner 22H. Power Flame (“C”) BAP No. “40”, 7-1/2” Dia. Hole 1 1 1 1 602263401
22 I. Power Flame (“C”) BAP No. “41”, 9” Dia. Hole 1 1 1 1 1 1 1 602263411 22J. Power Flame (“C”) BAP No. “42”, 10-3/8” Dia. Hole 1 1 1 1 602263421
- OR -
Gas Burner 22K. Power Flame (“JR”) BAP No. “45”, 6-3/8” Dia. Hole 1 1 1 1 602263451
22L. Power Flame (“JR”) BAP No. “41”, 9” Dia. Hole 1 1 1 1 602263411
23 Burner Adapter Plate Gasket (RCF) 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 8022601 24 3/8” Split-Lock Washer, Plated 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 80860650 25 3/8” -16 x 7/8” Lg. Hex Head Cap Screw, Plated 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 80861352 26 1/2” Flat Washer (USS), Plated 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 80860641 27 1/2”-13 Hex Nut, Plated 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 80860471 28 3” NPT Countersunk Pipe Plug, Black 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 806603509 29 Flue Outlet Damper Assembly, 7” 1 1 102471-01
Flue Outlet Damper Assembly, 8” 1 1 1 102471-02
Flue Outlet Damper Assembly, 10” 1 1 1 102471-03
Flue Outlet Damper Assembly, 12” 1 1 1 1 1 1 1 102471-04
30 Flue Outlet Damper Mounting Gasket 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 102472-01 31 Hex Head Cap Screw 5/16 - 18 x 7/8” Plated 12 12 12 12 12 12 12 12 12 12 12 12 12 12 12 80861371 32 Washer, Flat, 1/4” USS, Plated 12 12 12 12 12 12 12 12 12 12 12 12 12 12 12 80860803 33 4” NPT x 8” Lg - Supply/Return 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 806600603
REPAIR PARTS - COMMON BARE BOILER COMPONENTS (continued)
