83
Item
No.
Description
Boiler Sections / Quantity
Part No.
04 05 06 07 08 09 10 11 12 13 14 15 16 17 18
1 Jacket Frame-Horizontal Support Channel 1 1 1 2 2 2 2 2 3 3 3 3 3 4 4 100758-01
2 Jacket Frame-Horizontal Support Channel Bracket 2 2 2 4 4 4 4 4 6 6 6 6 6 8 8 100757-01
3
#8 x 1/2” Lg. Type AB, Slotted Hex Washer Head
Sheet Metal Screw, Steel, Plated
12 12 12 24 24 24 24 24 36 36 36 36 36 48 48 80860018
4 3/8” -16 x 3-1/2” Lg. Threaded Rod 2 2 2 4 4 4 4 4 6 6 6 6 6 8 8 101596-01
5 11/16” OD x 7/16” ID x 17/32” Lg. Spacer 4 4 4 8 8 8 8 8 12 12 12 12 12 20 20 101597-01
6 3/8” Flat Washer, USS, Plated 8 8 8 16 16 16 16 16 24 24 24 24 24 32 32 80860618
7 3/8” -16 Serrated Flange Hex Nut, Steel, Plated 4 4 4 8 8 8 8 8 12 12 12 12 12 16 16 80860498
8 Jacket Frame-Lower Front/Center Bracket 2 2 2 4 4 4 4 4 6 6 6 6 6 8 8 100760-01
9 5/8” -11 x 2” Lg. Hex Head Bolt, Plain 2 2 2 4 4 4 4 4 6 6 6 6 6 8 8 80860887
10 5/8” Flat Washer, USS, Plain 4 4 4 8 8 8 8 8 12 12 12 12 12 16 16 80860608
11 5/8” -11 Hex Nut, Plain 2 2 2 4 4 4 4 4 6 6 6 6 6 8 8 80860460
12 Jacket Frame-Vertical Side Channel (Painted) 2 2 2 4 4 4 4 4 6 6 6 6 6 8 8 100759-01
REPAIR PARTS - FRONT & CENTER SECTION FRAME RAIL ASSEMBLY
