Burnham MPC - Page 85

85
Item
No.
Description
Boiler Sections / Quantity
Part No.
04 05 06 07 08 09 10 11 12 13 14 15 16 17 18
1 Jacket Frame-Horizontal Support Channel 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 100758-01 2 Jacket Frame-Horizontal Support Channel Bracket 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 100757-01 3
#8 x 1/2” Lg. Type AB, Slotted Hex Washer Head Sheet Metal Screw, Steel, Plated
12 12 12 12 12 12 12 12 12 12 12 12 12 12 12 80860018
4 3/8” -16 x 13-3/4” Lg. Threaded Rod 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 101596-02 5 11/16” OD x 7/16” ID x 2-21/32” Lg. Spacer 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 101597-03 6 11/16” OD x 7/16” ID x 1-23/32” Lg. Spacer 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 101597-02 7 3/8” Flat Washer, USS, Plated 8 8 8 8 8 8 8 8 8 8 8 8 8 8 8 80860618 8 3/8” -16 Serrated Flange Hex Nut, Steel, Plated 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 80860498 9 Jacket Frame-Lower Rear Bracket 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 100761-01
10 5/8” -11 x 2” Lg. Hex Head Bolt, Plain 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 80860887
11 5/8” Flat Washer, USS, Plain 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 80860608
12 5/8” -11 Hex Nut, Plain 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 80860460 13 Jacket Frame-Vertical Side Channel (Painted) 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 100759-01
REPAIR PARTS - REAR SECTION FRAME RAIL ASSEMBLY
