Burnham MPC - Page 89

89
Item
No.
Description
Boiler Sections / Quantity
Part No.
04 05 06 07 08 09 10 11 12 13 14 15 16 17 18
1 Complete Heat Exchanger Wrapper Insulation
1A. 4” Thk Nominal x 32-5/8” x 140-3/4” Lg. 1 101835-04 1B. 4” Thk Nominal x 39-3/8” x 140-3/4” Lg. 1 101835-05 1C. 4” Thk Nominal x 46-1/8” x 140-3/4” Lg. 1 101835-06
2 Front Heat Exchanger Wrapper Insulation
2A. 4” Thk Nominal x 24-5/8” x 140-3/4” Lg. 1 101849-01 2B. 4” Thk Nominal x 31-3/8” x 140-3/4” Lg. 1 1 1 1 1 1 1 101849-02 2C. 4” Thk Nominal x 38-1/8” x 140-3/4” Lg. 1 1 1 1 101849-03
3 Center Heat Exchanger Wrapper Insulation
3A. 4” Thk Nominal x 27” x 140-3/4” Lg. 1 1 2 1 101851-01 3B. 4” Thk Nominal x 33-3/4” x 140-3/4” Lg. 1 1 1 1 101851-02
4 Rear Heat Exchanger Wrapper Insulation
4A. 4” Thk Nominal x 28-1/4” x 140-3/4” Lg. 1 1 1 101850-01 4B. 4” Thk Nominal x 35” x 140-3/4” Lg. 1 1 1 1 1 1 1 101850-02
4C. 4” Thk Nominal x 41-3/4” x 140-3/4” Lg. 1 1 101850-03
REP
AIR PARTS - HEAT EXCHANGER INSULATION WRAPPER
