91
Item
No.
Description
Boiler Sections / Quantity
Part No.
04 05 06 07 08 09 10 11 12 13 14 15 16 17 18
1 Primary Internal J-Box 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 101418-01
2 Secondary Internal J-Box Assy. w/Securing Channel 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 101533-01
3
#8 x 1/2” Lg. Type AB Slotted Hex Hd Washer Sheet
Metal Screw, Plated
6 6 6 8 8 8 8 8 10 10 10 10 10 12 12 80860018
4 Main Chase-way Channel:
4A. 27-9/16” Lg. 1 1 1 1 101432-01
4B. 34-5/16” Lg. 1 1 1 1 1 1 1 1 101432-02
4C. 41-1/16” Lg. 1 1 1 101432-03
5 Chase-way Channel Extension:
5A. 20-5/16” Lg. 1 101519-01
5B. 27-1/16” Lg. 1 1 2 2 1 3 2 101519-02
5C. 33-13/16” Lg. 1 1 1 2 2 1 101519-03
6
#8 x 2-1/2” Lg. Type AB Slotted Hex Hd Washer
Screw, SM, Steel, Plated
4 4 4 6 6 6 6 6 8 8 8 8 8 10 10 101757-01
7
7/64” Push On Plastic Edge Trim, Polyethylene, Blk,
(Cut Length = 16” Lg.)
1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 101846-01
8 Internal Wiring Harness Assembly:
8A. MPC4 Thru MPC8 1 1 1 1 1 101438-01
8B. MPC9 Thru MPC13 1 1 1 1 1 101438-02
8C. MPC14 Thru MPC18 1 1 1 1 1 101438-03
9 Nylon Cable Tie, Black, T&B #TY-525M or Equivalent 6 6 6 9 9 9 9 9 12 12 12 12 12 15 15 8136050
10
5/8” Dia. Cable Clamp, Black, Heyco #3380 or
Equivalent
2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 8136077
REPAIR PARTS - INTERNAL WIRING HARNESS COMPONENTS
