REPAIR PARTS - JACKET PANEL ASSEMBLY (continued)
Item
No.
Description
Boiler Sections / Quantity
Part No.
04 05 06 07 08 09 10 11 12 13 14 15 16 17 18
11 Jacket Rear Top Panel 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 100735-01
12 Internal J-Box Cover Plate 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 101190-01
13 7/8” Dia. Black Snap-in Plug, Alliance #S-78 8 8 8 8 8 8 8 8 8 8 8 8 8 8 8 100091-01
14 Jacket Side Panel Assemblies with Labels:
14A. 19-7/16” x 55-5/16” 1 101767-06
14B. 23-3/16” x 55-5/16” 1 101767-01
14C. 26-3/16” x 55-5/16” 1 1 1 1 1 1 1 101767-02
14D. 29-15/16/” x 55-5/16” 1 101767-03
14E. 32-15/16” x 55-5/16” 1 1 1 1 101767-04
14F. 36-11/16” x 55-5/16” 1 101767-05
15 Jacket Side Panels:
15A. 19-7/16” x 55-5/16” 1 100746-01
15B. 23-3/16” x 55-5/16” 1 2 2 2 100746-02
15C. 26-3/16” x 55-5/16” 1 1 3 3 1 5 3 100746-03
15D. 29-15/16” x 55-5/16” 1 2 2 2 2 2 2 2 100746-04
15E. 32-15/16” x 55-5/16” 1 1 2 3 3 2 100746-05
15F. 36-11/16” x 55-5/16” 1 2 2 100746-06
16
Snap-Bushing, Heyco SB-1093-15, #2166,
Black
4 4 4 8 8 8 8 8 12 12 12 12 12 16 16 8136257
17 MPC Logo Name Plate 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 101640-01
18A Jacket Left Front BSD Cover Panel Assy. 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 100748-01
18B Jacket Right Front BSD Cover Panel Assy. 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 100749-01
19 Jacket BSD Cover Hanger Bracket 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 100750-01
