Burnham MPC - Page 97

97
Item
No.
Description
Boiler Sections / Quantity
Part No.
04 05 06 07 08 09 10 11 12 13 14 15 16 17 18
1 2
nd
Pass Flueway Bafes, 304 Stainless Steel:
1A. 18” 2P Bafe Assembly w/Handles 4 101647-01
1B. 24¾” 2P Bafe Assembly w/Handles 4 101647-02
1C. 31½” 2P Bafe Assembly w/Handles 4 101647-03
1D. 38¼” 2P Bafe Assembly w/Handles 4 101647-04
1E. 45” 2P Bafe Assembly w/Handles 4 101647-05
1F. 51¾” 2P Bafe Assembly w/Handles 4 101647-06
1G. 58½” 2P Bafe Assembly w/Handles 4 4 4 101647-07
1H. 65¼” 2P Bafe Assembly w/Handles 4 4 101647-08
1J. 72” 2P Bafe Assembly w/Handles 4 4 101647-09
1K. 78¾” 2P Bafe Assembly w/Handles 4 4 101647-10
2
3
rd
Pass Flueway Bafe Assembly w/Handles,
25-1/4” Lg., Cold Rolled Steel
4 4 4 4 4 4 4 4 101652-01
REPAIR PARTS - MPC 2
ND
AND 3
RD
PASS FLUEWAY BAFFLES
