Installation | 5
Instruction Manual PANDA WV 0250-2000 C_EN_en 9 / 24
– DN63, DIN 28404 for WV 0250, 0500 C
– DN100, DIN 28404 for WV 1000, 1500 C
– DN160, DIN 28404 for WV 2000 C
Depending on the specific order, other connection dimensions may apply.
• Make sure that the discharged gas will flow without obstruction. Do not shut off or
throttle the discharge line or use it as a pressurised air source.
5.3 Filling Oil
NOTICE
Use of an inappropriate oil.
Risk of premature failure!
Loss of efficiency!
• Only use an oil type which has previously been approved and recommended by
Busch.
For oil type and oil capacity see Technical Data [►22] and Oil [►22].
1
5
3
MAX
MIN
2
Busch Oil
Busch Oil
4
Check oil level
Fill up until the
oiler (OR) is at least
two thirds full
Oil filling at the motor side
(with lip seals only)
