Bush AB320 - Installing the Doors

10
Customer Helpline 0845 600 4632
Installation
Installation
b: Secure the fi xing bracket (G) to the kitchen unit
using screws (E), as shown in (7). Repeat for the
opposite side
a: Secure the guides (C) to the appliance doors
using screws (E), as shown in (8).
b: Open the appliance doors to right angles and
position the unit door against the appliance door.
c: Raise the rails (D) onto the guides (C) aligning
with the groove.
d: Secure the rails (D) to the unit doors using screws
(E).
e: Set a 1-2mm gap on the handle side between the
unit itself and the unit doors by adjusting guides
(C) and screws (F) as necessary.
Installing the doors
E
C
D
F
E
E
G
8
7
