9
Customer Helpline 0845 600 4632
Caution: Two people are required to
handle the appliance. It is recommended
that gloves are worn.
a: Carefully move the appliance into position into the
kitchen unit.
b: Push the appliance back to the reverse side
of the door hinges, and make sure that the
trim gasket (B) covers the space between the
appliance and the kitchen unit.
c: Align the front feet with the front surface of the
kitchen unit.
d: Screw the front feet with screws (E), as shown in
(5).
Installation
Installation
a: Secure the trim fl ap (A) to the kitchen unit using
screws (E), as shown in (6).
Continued on next page.
Position the appliance
Securing the appliance
E
E
6
5
To Next Page
