Getting to know your Soundbar
You’ll be up and running in no time
DC IN
SUB
TV (Digital connection)
TV (Non-digital connection)
Digital coaxial or
optical audio output
MP3 player, Smart
phone or other audio
equipment
DVD, Bluray player,
Games console with
digital coaxial or optical
output
COAXIAL
OPTICAL
AUX
3.5mm audio socket
(such as earphone)
Sub woofer
input cable
Making the connections
Follow the below connection guide to connect the Q5S Soundbar to a TV, DVD/Bluray or games console with a
digital coaxial OR optical output, a non-digital TV or external audio source such as an MP3 player or smartphone.
NOTE: DO NOT power on the mains until all other connections are made.
