1.12 Specifications
(May vary depending on optional configurations and equipment installed) Refer to Form WB-1
specific to this model and configuration. Jabiru Engine performances may vary from those shown
below.
ENGINE ROTAX 912 – 80 h.p. ROTAX 914 –115 h.p. FLOATS
LENGTH
22 ft. 1in. 22ft.1in. 22 ft. 1in.
HEIGHT
6 ft 6 ft 6 ft
AILERON
Left wing travel up 22 Left wing travel up 22 Left wing travel up 22
AILERON
Left wing travel down 21
Left wing travel down 21
Left wing travel down 21
AILERON
Right wing travel up 25 Right wing travel up 25 Right wing travel up 25
AILERON
Right wing travel down 19 Right wing travel down 19 Right wing travel down 19
ELEVATOR
Travel down 31.5
Travel down 31.5 Travel down 31.5
ELEVATOR
Travel up 22 Travel up 22 Travel up 22
RUDDER
Right 15.25”
Right 15.25” Right 15.25”
RUDDER
Left 18” Left 18” Left 18”
WING SPAN 32 feet 32 feet 32 feet
WING AREA 168 sq. ft. 168. Sq. ft 168. Sq. ft.
CEILING 10,000 ft. 12,,000 ft. 10,000 ft.
MAX WEIGHT 1320 lbs. 1320 lbs` 1430 lbs
EMPTY WEIGHT 751. 751 lbs. 835
USEFUL LOAD 569. 569 lbs. 595
CRUISE 75% 95 MPH 105 MPH 84 – 96 MPH
VNE 130 MPH 130 MPH` 130 MPH
VA 58 MPH 58 MPH 58 MPH
STALL power off 34 MPH 34 MPH 34 MPH
Power/weight ratio 15 lb/BHP 10.43 lb/BHP 14.8 lb/BHP
WING LOADING 7.3 lb per sq. ft. 7.3 lb. Per. Sq. ft. 7.3 lb. Per sq. ft.
TAKE OFF 1332 lb. 266 ft. concrete
282 ft. short grass
300 ft. tall grass
305 ft. soft ground
266 ft. concrete
270 short grass
300 tall grass
300 soft ground
15-30 seconds at gross
RATE OF CLIMB 850 f.p.m. 1000 f.m.p. 600 f.p.m.
WING
A) Average Aerodynamic Line 63.5”
B) Line of Incidence 0.05
C) Dihedral 1.125” at the tip of the wing
CONTROL SURFACES
A) Wings and Ailerons 168 sq.ft.
B) Ailerons 17.94 sq.ft.
C) Horizontal Stabilizer 15.68 sq.ft.
D) Elevator 11.0 sq.ft.
E) Vertical Stabilizer 8.3 sq. ft.
F) Rudder 4.5 sq.ft.
