BushCADDY LSA Pilot Operating Handbook Rev.03 5 March, 2008
Page 17 of 52
WEIGHT AND BALANCE
SKIS
DATE: SERIAL NO:
SERIAL NO: DATUM: Leading edge of wing
REGISTRATION: MAX GROSS: 1320 lbs.
LANDING GEAR CONFIGURATION: Floats USEFUL LOAD
Aircraft must be placed level on scales, hangar doors closed, fuel tanks drained and engine oil included
WEIGHT (LBS)
Right ski
Left ski
Tail ski
TOTAL WEIGHT
Net empty weight
Centre of Gravity
Max. Gross 1320 lbs.
Useful load
NOTE
The limits of the center of gravity must be within 15 – 22 inches.
Weight Total empty
weight
Arm Moment
Aircraft
Passenger
Fuel
Luggage
TOTAL
C.G. =
NOTE: RECORD THE WEIGHT ON EACH SKI; DEDUCT THE TARE FROM EACH
READING
WARNING! Prevent aircraft movement during weighing procedure. Raise tail carefully, the
higher the tail is lifted, the lighter it becomes. Aircraft can nose over
