• Push up the switch to the “unlock” side, remove the plug, then take out the roller
brush.
Ensure the appliance is disconnected from the charger before removing
the roller brush. Be careful not to pull the ON button.
• Put the stainless steel filter from the bottom of the dust cup and rotate it tightly (There
are 3 small protrusions on the stainless steel filter's edg corresponding to the 3 small
grooves on the dust cup).
• Put the HEPA filter from above, and cover the dust container Bottom cover Bottom.
Note：The function of the air filter element is to allow the device to dissipate heat and
dredge the air more effectively during operation, without frequent cleaning. If neces-
sary, press the air filter release button to remove the air filter.
• Align the convex part of the handle with the concave part of the dust cup and insert it,
and then press the release button of the dust cup to completely close the dust cup and
the handle.
Reinstallation
Air Filter
sales@ibuture.com
EN
01 02 03 04 05 06 07 08 09 10 11 12
13 14 15 16 17 18 19 20 21 22 23 24
25 26 27 28 29 30 31 32 33 34 35 36
37 38 39 40 41 42 43 44 45 46 47 48
49 50 51 52 53 54 55 56 57 58 59 60
61 62 63 64 65 66 67 68 69 70 71 72
2. Clean the brush.
