User’s Manual
III
Specification:
This manual covers three different layout models, and the respective board layouts
are shown in chapter 1-4. Please refer to the following description to make sure
which model on hand before using.
ENDAT-3201M ENDAT-3201MF ENDAT-3201MH
System Chipset
VIA VT8601A + VIA VT82C686B (APOLLO PLE-133)
Micro Processor
Embedded Low Power Consumption VIA Eden 533 MHz or C3-800 MHz CPU
Memory
1 DIMM Socket up to 512MB (max)
Ethernet
10/100 BaseT LAN onboard (Realtek 8139C or Intel 82559ER)
LCD / VGA
Support 24 Bits TFT LCD Panel with 2D / 3D Graphic Controller, SMA up to 8MB
IDE Connector
1x Enhance IDE Connectors Support UDMA 33/66/100
FDD Connector
1x FDD Connector
Expansion Slot
1x 188Pin EISA Connector for PCI/ISA expansion.
Flash Memory
Reserved Socket for DOC 2000 support
Keyboard / Mouse
Double-Deck + Pin Header Double-Deck + Pin Header Pin Header
LAN/USB
USB+LAN Double-Deck
USB+LAN Double-Deck
& USB Pin Header
USB Pin Header
RJ-45 LAN Jack
COM 1
Double-Deck
(COM 1+LPT1+VGA)
Double-Deck
(COM 1+LPT1+VGA)
Box Header
COM 2
D-SUB D-SUB Box Header
COM 3
D-SUB Box Header Box Header
COM 4
D-SUB Box Header Box Header
LPT 1
Double-Deck
(COM1+LPT 1+VGA)
Double-Deck
(COM1+LPT 1+VGA)
Box Header
LPT 2
Box Header Box Header Box Header
VGA
Double-Deck
(COM1+LPT1+VGA)
Double-Deck
(COM1+LPT1+VGA)
& Box Header for VGA
Box Header
TFT LCD Connector
44 Pin Box Header
LVDS output
Optional LVDS for LCD output via 16 Pin Header.
Watch Dog Timer
Optional programmable Watch Dog Timer support 1-255s.
RS-422/485
Optional via COM2
COM Port Power
4 Serial port support Standard RI. / +5V / +12V power via Pin 9
Boot ROM
Reserve Socket for Boot ROM
Power Supply
AT or ATX Power support.
Form Factor
SBC / 203mm x 146mm (7.99” x 5.74”)
IV
The low power consumption CPU embedded board
