BWI ENDAT-3201M - Power Management Setup

User’s Manual 41
Serial Port IRQ
This option specifies the IRQ used by the serial port.
The default settings are (IRQ)3, (IRQ)4, (IRQ)9 and (IRQ)10.
Onboard AC' 97 Audio
This function is to disable or enable AC’97 Audio. Choices: Auto; Disabled
Onboard Legacy Audio
This function allows configuring the Audio Codec to support legacy Sound Blaster
mode. Choices: Auto; Disabled
Sound Blaster
This option is to Enable / Disable the onboard Audio support Sound Blaster
decoding.
SB I/O Base Address
To configure the Sound Blaster decoding I/O range.
Choice: 220h – 280h
SB IRQ Select
To configure Sound Blaster IRQ channel.
Choice: 5,7 and 10
SB DMA Select
To configure Sound Blaster DMA channel.
Choice: 0,1,2 and 3
MPU-401
This option is to Enable / Disable onboard MIDI port decoding.
MIPU-401 I/O Address
If the onboard MPU-401 port is “Enabled”, it allows to set at 300h/310h/320h or
330h.
MPU-401
Allows you to Enable / Disable onboard MIDI port,
Game Port (200h-270h)
This option allows configuring onboard Game port address. The choices: Disabled;
200h; 207h
42 The ENDAT-3201M/MF/MH Embedded CPU Board
3-6. Power Management Setup
Power Management Setup
Power Management/APM Enabled
Video Power Down Mode Disabled
Hard Disk Power Down Mode Disabled
Standby Time Out (Minute) Disabled
Suspend Time Out (Minute) Disabled
Display Activity Ignore
IRQ3 Monitor
IRQ4 Monitor
IRQ5 Ignore
IRQ7 Monitor
IRQ9 Ignore
IRQ10 Ignore
IRQ11 Ignore
IRQ13 Ignore
IRQ14 Monitor
IRQ15 Ignore
Power Button Function On/Off
Restore on AC/Power Loss Power On
Power Management/APM
Set this option to Enabled to enable the chipset power management and APM
(Advanced Power Management) features. The settings are Enabled or Disabled.
Video Power Down Mode
This option specifies the power state that the video subsystem enters when
AMIBIOS places it in a power saving state after the specified period of display
inactivity has expired. The settings are Standby, Suspend or Disabled.
Hard Disk Power Down Mode
This option specifies the power conserving state that the hard disk drive enters after
the specified period of hard drive inactivity has expired. The settings are Disabled,
Standby, or Suspend.
Standby/Suspend Timer Unit
This option specifies the unit of time used for the Standby and Suspend timeout
periods. The settings are 4 msec, 4 sec, 32 sec, or 4 min.
