User’s Manual 37
3-4. Details of the Advanced Chipset Setup
Advanced Chipset Setup
******** DRAM Timing ********
Configure SDRAM Timing by SPD Enabled
DRAM Frequency 133Mhz
SDRAM CAS# Latency 3
DRAM Bank Interleave Enabled
Memory Hole Disabled
AGP Mode 4x
AGP Read Synchronization Enabled
AGP Fast Write Enabled
AGP Aperture Size 128MB
AGP Master 1 W/S Write Disabled
AGP Master 1 W/S Read Disabled
PCI Delay Transaction Enabled
USB Controller All USB Port
USB Device Legacy Support All Device
Port 64/60 Emulation Disabled
Configure SDRAM Timing by SPD
SPD (Serial Presences Detect) is a device in memory module for storing the module
information such as DRAM timing and chip parameters. If this option is enabled,
BIOS will access SPD automatically to configure module timing. If disabled,
DRAM timing can be configured manually.
z SDRAM Frequency
Allows you to set the SDRAM frequency with user set by SPD Disable.
<Choices: 66MHz / 100MHz / 133MHz>
Caution: Improper setting will cause unpredicted result
z SDRAM CAS# Latency With SDRAM Timing by SPD disabled, you can
select
The SDRAM CAS# (Column Address Strode) latency manually. Choices:
2 Clocks; 3 Clocks
38 The ENDAT-3201M/MF/MH Embedded CPU Board
SDRAM Bank Interleave
This function is to enable / disable SDRAM Bank Interleave function. Choices:
Disabled / Enabled
Memory Hole
To enabled / disabled (default) the support of Memory Hole which is reserved for
ISA card.
AGP Mole
This function allows seeing the AGP Mode onboard. The default setting is “Auto”.
This item support 1x/2x and 4x AGP Mode
AGP Read Synchronization
To enabled / disabled the AGP Read Synchronization function.
AGP Fast Write
This function allows enabling / disabling the AGP Fast Write function
AGP Aperture Size
This function allows adjusting AGP Aperture Size from 2MB to 256MB to
increased VGA performance.
AGP Master 1 W/S Write
Allows you to enable / disable the AGP Master Write with 1 wait state
AGP Master 1 W/S Read
To enable / disable the AGP Master Read with 1 wait state
PCI Delay Transaction
To enable / disable the AGP Fast Write function
USB Controller
To enable / disable the on board USB Port function
Choices: USB Port 0&1 / USB Port 2&3 / All USB Device
USB Device Legacy Support
To enable / disable the on board USB support device with
Choices: Disabled / No Mice / All Device
Port 64/60 Emulation
To enable / disable the on board USB to support Mouse under NT4.0.
The default setting is “Disabled”, Choices: Enabled / Disabled
