Chapter 1. Introduction
In order to cope with the challenges of the heating issues and demand of much more
diminutive embedded system in diverse application, ENDAT-3201M/MF/MH series CPU
boards provides the ultimate solution by integrating with VIA’s technology low power
consumption VIA C3 series CPU and VIA EDEN fanless ESP series CPU. ENDAT-3201M
series CPU boards offer the assorted functions for various applications such as high-end POS
systems, kiosks, networking systems, controlling terminals and other embedded systems.
ENDAT-3201M/MF/MH is a 5.25” SBC uses
VIA chipsets built-in VGA and Audio
feature onboard, support TFT TTL LCD feature with LVDS interface as feature option;
i
ntegrated Super-I/O support 4 Serial with power selector and 2 parallel ports,
built-in Realtek 8139x LAN chipset with RJ45 Jack for 10BaseT/ 100BaseT. The option of
Intel 82559/ER chip is also provided for the LAN support. This SBC offers the highest
performance PC specification in the industry with embedded low power consumption VIA
EDEN Fanless ESP series CPU ESP5000, and with the option of the higher performed VIA
C3 800MHz CPU. For easier assembly and better integration without arranging array of
cables, the ENDAT-3201M/MF provides onboard connectors with a similar conventional
ATX IO connector layout; as for ENDAT-3201MH leaves the flexibilities of cable
connections similar to the standard 5.25” SBC.
ENDAT-3201M/MF/MH provides the option of integrating Watch Dog Timer for
ideal unattended terminals. To offer better flexibility, it also provides the options of
riser card for PCI or ISA expansion through a 188-pin slot. This CPU board is fully
compatible with industry standards, adding many technical enhancements and are
fully compatible with thousand of software application such as WIN 95, 98, WIN
NT 3.x / 4.x, WIN 2000, WIN ME, WIN CE (.NET), Linux, UNIX, Novell…etc.
The control logic provides high-speed performance for the most advanced
multi-user, multitasking application available today. “Tomorrow’s PC technology
is here today”.
2
The ENDAT-3201M/MF/MH
Embedded CPU Board
1-1. Features
Basic Feature:
z ENDAT-3201M/MF/MH, embedded VIA
C3
TM
, Eden
TM
, Ezra
TM
Low
Power EBGA processors.
z 133 / 100 MHz CPU Front Side Bus (FSB)
z DRAM interface synchronous or pseudo synchronous with CPU FSB speed
of 133 / 100 / 66 MHz Mixed 1M / 2M / 4M / 8M / 16M / 32MxN DRAMs
z 1 DIMM 168 Pin socket supported up to 512MB
z 3.3V DRAM interface with 5V-tolerant inputs
z Support single channel support two UltraDMA-100 / 66 / 33 enhance IDE
z AC-97 link.
z On-board built-in 2 USB ports.
z Integrated Super-I/O support 4 Serial with power selector and 2 parallel
ports.
z Optional RS-422/485 via COM2
z System Hardware monitoring
z Keyboard / mouse interfaces.
z RTC / CMOS
z PCI-2.0 compliant, 32 bit with 5V tolerant inputs.
z 33 MHz operation on the primary PCI bus
z 188pin expansion slot for both PCI and ISA Bus signals.
z PC99 Hardware Support
z Watch-Dog-Timer support 1-255sec programmable.
z On-board support Realtek or Intel 82559/ER 10/100 LAN adapter with
RJ-45 port.
z AGP v2.x compliant
z Integrated AGP Bus 2D / 3D graphic accelerator.
z Windows 95 OSR-2 VXD and integrated Windows 98 / NT 4.0 miniport
driver support
z BIOS shadow at 16KB increment
