User’s Manual
3
z Supports 2, 4 and 8 Mbytes of Frame Buffer with share memory.
z DirectDrawTM and DirectVideoTM Hardware Support
z Advanced Mobile Power Management
z CRT Power Management (VESA™ DPMS)
Optional for Flat Panel Interface (TTL or LVDS)
The board is designed to support industry standard TFT panel via 44pin connector
or LVDS transmitters. The interface supports both 18-bit and 24-bit display modes.
Optionally, an 18+18 panel can be supported utilizing external latches.
Optional Features
•
Supports RS422/RS485 interface with COM2
•
Support LVDS LCD panel
•
Supports Audio function (via AV Card Kit)
•
Supports TV-Out feature (via TV-Out adapter Kit)
•
Support Watch Dog Timer
•
Support BOOT ROM
Ordering information:
ENDAT-3201M
1. ENDAT-3201M-1R: Support 1 Realtek LAN
2. ENDAT-3201M-1i: Support 1 Intel LAN
3. ENDAT-3201M-1RL: Support 1 Realtek LAN + LVDS
4. ENDA-3201M-1iL: Support 1 Intel LAN + LVDS
ENDAT-3201MF
1. ENDAT-3201MF-1R: Support 1 Realtek LAN
2. ENDAT-3201MF-1i: Support 1 Intel LAN
3. ENDAT-3201MF-1RL: Support 1 Realtek LAN + LVDS
4. ENDA-3201MF-1iL: Support 1 Intel LAN + LVDS
4
The ENDAT-3201M/MF/MH
Embedded CPU Board
ENDAT-3201MH
1. ENDAT-3201MH-1R: Support 1 Realtek LAN
2. ENDAT-3201MH-1i: Support 1 Intel LAN
3. ENDAT-3201MH-1RL: Support 1 Realtek LAN + LVDS
4. ENDA-3201MH-1iL: Support 1 Intel LAN + LVDS
Note: The standard version of ENDAT-3201M/MF/MH is embedded with VIA EDEN
Fanless ESP5000. Other option CPUs will be provided upon request.
