BWI ENDAT-3201M - Page 36

User’s Manual 65
LCD - LVDS Output Connector (CN5)
TFT LCD Panel Port Connector (LCD-CON1)
Pin No. Signal Pin No. Signal
1 VBL 2 VBL
3 GND 4 GND
5 VDDLCD 6 VDDLCD
7 ENPVEE 8 GND
9 FPD 23 10 FPD 22
11 FPD 17 12 FPD 16
13 FPD 11 14 FPD 10
15 FPD 9 16 FPD 8
17 FPD 21 18 FPD 20
19 FPD 15 20 FPD 14
21 FPD 7 22 FPD 6
23 FPD 5 24 FPD 4
25 FPD 19 26 FPD 18
27 FPD 13 28 FPD 12
29 FPD 3 30 FPD 2
31 FPD 1 32 FPD 0
33 GND 34 GND
35 P_CLK 36 FLM
37 DE 38 LP
39 GND 40 VDDLCD
41 VDDLCD 42
KEY
43 VDDLCD 44 VDDLCD
Pin No. Signal Pin No. Signal
1 Y0– 2 Y2–
3 Y0+ 4 Y2+
5 Y1– 6 Rcv. Voltage
7 GND 8 Y3–
9 Y1+ 10 Y3
11 CK– 12 VDD_PNL
13 CK+ 14 DISP_OFF
15 VBL 16 GND
66 The ENDAT-3201M/MF/MH Embedded CPU Board
Audio Output Port Connector (CN1)
Pin No. Function Pin No. Function
1 BITCLK 2 GND
3 SDIN 4 N.C.
5 SDIN2 6 N.C.
7 SDOUT 8 N.C.
9 SYNC 10 GND
11 –ACRST 12 GND
13 SPEAK 14 Strapping Low
15 +5V(DC) 16 +12V(DC)
17 JBCY 18 JAB2
19 JBCX 20 JAB1
21 JACY 22 JBB2
23 JACX 24 JBB1
25 MSO 26 MSI
IR Connector (J1)
Pin 1
VCC
Pin 4
GND
Pin 2
N.C
Pin 5
IRTX
Pin 3
IRRX
