BWI ENDAT-3201M - Page 38

User’s Manual 69
Pin No. Description C Description D Description G Description H
1
–SBHE –MEMCS16 N.C –SERR
2
LA23 –IOSC16 N.C AD15
3
LA22 IRQ10 –CBE1 AD14
4
LA21 IRQ11 PAR AD12
5
LA20 IRQ12 GND GND
6
LA19 IRQ13 KEY KEY
7
LA18 IRQ14 GND GND
8
LA17 –DACK0 AD13 AD10
9
–MEMR DRQ0 AD11 AD8
10
–MEMW –DACK5 AD9 AD7
11
SD8 DRQ5 –CBE0 AD5
12
SD9 –DACK6 AD6 AD3
13
SD10 DRQ6 AD4 AD1
14
SD11 –DACK7 AD2 AD0
15
SD12 DRQ7 KEY KEY
16
SD13 VCC VCC VCC
17
SD14 MASTER VCC VCC
18
SD15 GND GND GND
19
GND GND
Power connector
ATX AT
3.3V
11 1
3.3V
POWER GOOD
1
–12V
12 2
3.3V +5V
2
GND
13 3
GND
+12V
3
PS ON
14 4
+5V
–12V
4
GND
15 5
GND GND
5
GND
16 6
+5V
GND
6
GND
17 7
GND GND
7
–5V
18 8
POWER OK GND
8
+5V
19 9
5V SB –5V
9
+5V
20 10
+12V +5V
10
+5V
11
+5V
12
