12. Technical Data
AQA nano
Connection nominal diameter DN 25
Connection thread outside thread 1”
Limescale protection up to max. 20°dH m
3
/h max. 1.5
l/min. max. 25
l/min. min. 0,6
Limescale protection capacity m
3
max. 110 ± 10*
months max. 12
Operating pressure PN bar 16
Temperature water inflow max. °C 30
Temperature environment max. °C 40
Temperature boiler max. °C 80
Dimensions of device & connection
dimensions:
Width x height mm 300 x 710
Fitting length (with screw connections) mm 234
Clearance: Wall middle of pipe mm 80 to 100
Weight kg ca. 11
Cable length mm 1000
Mains connection Volt/Hertz 230/50, 110/60 **
Electrical connected rating Watt 5.5
Capacity stand-by operation Watt 1.8
Energy consumption per m
3
water kWh 0.018
Type of protection IP 54
* depending on water quality
** country-specific
13. Technical Drawing
AQA nano
Flow direction left to right
AQA nano
Flow direction right to left
