BWT Bewades 70W70/08 HI

Questions and Answers

N
Nichole MeadowsAug 6, 2025
What to do if the displayed emission power is unusually low in my BWT Water Filtration System?
- R
  Robert MorganAug 6, 2025
  If the emission power is unusually low, it could be due to several reasons. The UV transmission of the drinking water might be too low, requiring feed water treatment through filtration. Alternatively, iron or manganese deposits may have formed, necessitating the removal of deposits on the UV emitter casing tube and sensor window, with possible replacement of the tube. Other potential causes include UV emitters exceeding their service life (EOL), requiring replacement, a misaligned UV emitter (rotate slightly), faulty UV emitters (replace), sensor malfunction (replace sensor), air bubbles in front of the sensor window (relieve pressure and re-install sensor window), or electromagnetic interference (eliminate the interference signal).
M
Mitchell RiveraAug 15, 2025
Why does my BWT Water Filtration System UV-Control II display the error message !LAMP! out?
- S
  Susan SmithAug 15, 2025
  The error message !LAMP! out indicates a problem with the UV emitter. It could be defective, requiring inspection or replacement. Another cause might be a faulty ballast, which would need to be replaced. Also, check the UV emitter signal cable for contact faults. The supply network fluctuations may also be the reason.
A
Ashley MirandaAug 26, 2025
How to fix water in the UV emitter casing tube of my BWT Water Filtration System?
- E
  Erin VillanuevaAug 26, 2025
  Water in the UV emitter casing tube can occur due to condensation when operating the unit without the blue protective cap. To resolve this, check the installation of the UV emitter casing tube and seals. Ensure the blue protective cap is correctly positioned, and replace the O-ring if needed.
