BWT PERMAQ compact 4 - Page 40

EN
40
DATE / TIME
CONDUCTIVITY / TDS
OPERATION MODE
LANGUAGE
BACK
AUTO RINSE
SERVICE
STOP DELAY
SETUP
BACK
STOP AT
60 sec
STOP AT
15 sec
Setting range: 0 ... 60 seconds
Observe: setting is deactivated at 0 sec.
Note: The given setting for the adjusting
range of the pressure values is only valid
for the mode „pressure tank operation
YES“.
The mode of “pressure tank OFF“ is with
the „stop pressure“ fixed at a value of
2.0 bar.
Fig. 14: Programming procedure: “OPERATION MODE“, “STOP PRESSURE“ and “FLUSH TIME“ – Example scheme
OPERATING MODE
START PRESSURE
STOP PRESSURE
BACK
PASSWORD
_ _ _ _ _ _
STOP AT 2.1 bar
STOP AT 3.1 bar
OPERATING MODE
START PRESSURE
STOP PRESSURE
BACK
* PRESSURE TANK “YES“
PRESSURE TANK “NO“
BACK
* PRESSURE TANK “YES“
PRESSURE TANK “NO“
BACK
PRESSURE TANK “YES“
* PRESSURE TANK “NO“
BACK
PRESSURE TANK “YES“
* PRESSURE TANK “NO“
BACK
DATE / TIME
CONDUCTIVITY / TDS
OPERATION MODE
LANGUAGE
BACK
Fig. 13
to call up the “LANGUAGE“ menu point, please refer to Fig. 12
PASSWORD:
OPERATING MODE
START PRESSURE
STOP PRESSURE
BACK
Setting range:
“Stop pressure“ 2.0 ... 4.0 bar
“Start pressure“ the value selection of
the start pressure (ON/OFF, hysteresis)
is between 0.3 ... 1.6 bar selectable
» incremental steps « : [+/- 0.1 bar]
Fig. 18
