Fitting and operating instructions EN
WS Range: WS355
WS455
WS555
WS655
WS755
BWT WS Range /09-2012 © BWT UK Limited
Changes of technical details are reserved
Important notice: Always keep the fitting and operating instructions
close at hand to avoid any mistakes and before carrying out any work
on the device, you should read the fitting and operating instructions
carefully and follow them. While our data sheets and brochures should
provide advice to the best of our knowledge, the content thereof is not
legally binding.
BWT WS Range
Water Softener
WS Cover.pdf 1 02/01/2014 13:29

Questions and Answers

  • Y
    ymosesSep 3, 2025
    What to do if water still remains hard from BWT Water Dispenser?
    • M
      Morgan RodriguezSep 4, 2025
      Fill the brine cabinet with salt, switch the power on and check connections, close the by-pass valve and open the inlet and outlet valves, and reset the hardness if required.
  • D
    Diana ClarkSep 18, 2025
    How to reduce excessive salt usage in BWT WS755 Water Dispenser?
    • M
      mcochranSep 18, 2025
      If your BWT Water Dispenser is using excessive salt, reduce the hardness setting if it is incorrect.
  • C
    Carrie BryantSep 16, 2025
    Why does the water from my BWT Water Dispenser still remains hard?
    • W
      wjacksonSep 16, 2025
      If the water from your BWT Water Dispenser still remains hard, ensure that the brine cabinet is filled with salt. Also, switch the power on and check the connections. Make sure the by-pass valve is closed, and the inlet and outlet valves are open. If necessary, reset the hardness.
  • D
    Dr. John James MDSep 14, 2025
    What to do if the water level in brine cabinet of BWT WS755 Water Dispenser reaches overflow?
    • J
      Jack MorrisSep 14, 2025
      If the water level in the brine cabinet of your BWT Water Dispenser reaches overflow, check the following: * Ensure the line pressure is within the specification (1.7 - 5.0 bar) by connecting a pressure gauge to a water outlet. * If the pressure falls outside this range, fit a pressure reducing valve or booster pump as needed. * Also, check that the drain line is not kinked, blocked, or frozen. * Finally, check that the power is on and the connections are secure, especially after a power interruption.
  • D
    Daniel RaySep 12, 2025
    What to do if there is no water from BWT WS755 Water Dispenser?
    • M
      mitchellnicoleSep 12, 2025
      First, open the mains stop valve. Then, open the inlet and outlet valves to the water softener.
  • R
    Ryan CarneySep 12, 2025
    What causes excessive salt usage in BWT Water Dispenser?
    • M
      Miss Rachel OliverSep 12, 2025
      Excessive salt usage may be due to an incorrect hardness setting. Reduce the hardness if it is set too high.
  • E
    edgar39Sep 9, 2025
    Why does BWT Water Dispenser run from the drain constantly?
    • L
      Larry WeaverSep 9, 2025
      If the unit is in recharge mode, this is normal; wait until the recharge is complete. If it is not in recharge mode, isolate the softener and call for service.
  • K
    Kara BlackwellSep 7, 2025
    How to fix hard water with BWT WS755 Water Dispenser?
    • Z
      zachary10Sep 7, 2025
      To address hard water issues, start by filling the brine cabinet with salt. Then, switch the power on and check the connections. Ensure that the by-pass valve is closed and the inlet and outlet valves are open. Finally, reset the hardness setting if necessary.
  • A
    Alexis TaylorSep 5, 2025
    What to do if the water level in brine cabinet reaches overflow in BWT WS755 Water Dispenser?
    • M
      Matthew RangelSep 5, 2025
      First, check if the line pressure is within the water softener's specification by connecting a pressure gauge to a water outlet; it should be between 1.7 - 5.0 bar. If the pressure falls outside this range, fit a pressure reducing valve or booster pump as required. Also, ensure the drain line is not kinked, blocked, or frozen and check that the power is on and the connections are secure.
  • D
    Dr. Timothy Cox DDSAug 20, 2025
    What to do if my BWT WS755 Water Dispenser unit regenerates at the wrong time?
    • K
      Krista SchaeferAug 20, 2025
      Reset the present time and the regeneration time.

Summary

Warning and Safety Instructions

General Safety and Operational Precautions

Covers electrical safety, correct application, child safety, and temperature protection.

Installation and Operating Considerations

Preparation and Positioning

Advice on site selection, space, weight, and access for installation and maintenance.

Installation Specifics and Drinking Water Advice

Installing Your Water Softener

Initial Setup and First Use

Programming the Water Softener

Setting Time and Water Hardness

Guide to setting the current time and inputting the measured water hardness level.

Setting Recharge Time

Procedure to define the automatic regeneration cycle's daily timing.

Troubleshooting: Water Still Hard

Salt Level and Power Checks

Resolving hard water issues by checking salt levels and power connections.

Softener Online and Hardness Setting

Troubleshooting steps for ensuring the softener is online and hardness settings are correct.

Troubleshooting: Operational Faults

No Water or Drain Flow Problems

Diagnosing and resolving issues with no water supply or constant drain flow.

Salt Usage, Display Errors, and Regeneration Timing

Addressing excessive salt usage, display errors, and incorrect regeneration timing.

BWT WS755 Specifications

General IconGeneral
BrandBWT
ModelWS755
CategoryWater Dispenser
LanguageEnglish
