Both red and black wire are connected to the speaker (output: 100V/COM), and
please neglect + or -. However, the speaker must be equipped with an
autotransformer; otherwise it might be damaged.
2. Remote Decoder (WMP-60) is attached to the outside.
※ Note
The connection applies to any kind of high speakers. (Chart 3)
1. Parallel connection and color management is applied. Simply connect green to
green, white to white, blue to blue, red to red…etc.
2. Users are able to connect external speakers (ceiling speakers, horn
speakers…etc.), simply connect both red and black wires (Fig. 4) to the
speaker’s output autotransformer (there is no difference between cathode and
anode)
