Product warranty
The Product warranty period is two (2) years from the sales date as mentioned in the
seller`s invoice to the End
User (“Invoice Date”).
1. Introduction
This is a simple manual for the charger, which is used to charge battery modules of BYD
Battery-Box HV; PRO, LV products in Europe. It will utilize power from grid and store it in the
battery module. So this is specialized for specific battery modules, if you force it to charge
similar battery, it will cause potential risks.
2. Connection
2.1 Check List
Overview of package list:
Name Description picture
Power
Cable
Power cord for connecting DC charger
AC input
Charging
cable
Please choose the correct wire to
connect to the type of battery (See
chapter 5.3)
DC
Charger
Charger is used to charge battery
modules.
Block
Block is used to form a circuit loop for
battery module.
Connect the power cable between grid and charger:
