Push Installation.
If there is no hole to accept the wires to your
new bell push, drill a 5mm hole through your
doorframe in your choosen position.
Undo the small screw located on the under-
side of the cover and remove the wall brack-
et. Fix the wall bracket to the door frame
using the 2 screws provided. Ensure the
bracket is mounted with the grub screw hole
at the bottom. From inside, push the bell wire
through the 5mm hole in the door frame
through the wall bracket. (fig.1)
Attach the bell wire to the terminals on the
back of the push button, making sure the
wires DO NOT touch. (fig.2)
Fit the bell push cover back onto the wall
bracket and tighten the small grub screw
located on the underside of the bell push
cover.
Products may vary slightly from the illus-
