Instruction manual
13
• I hear interference on the
line.
• Move other electronics away
from the unit to minimize
interference.
• There is no sound between
the outdoor unit and the
indoor unit.
• The microphone may be
obstructed. Clean the
microphone.
• Check that the cables are
connected and fastened
properly.
• I cannot talk or see video
when I press the intercom
button.
• When the outdoor unit is
used on battery, you can only
talk or see the video feed
when the doorbell is pressed.
This is for battery capacity
reasons.
7 Technical Data
• The appliance is suitable for domestic use only.
General Operating
Frequency
2400-2483.5MHz
Transmission rate 15~25fps(only effective
distance)
Unobstructed
effective range
200m
TX power 14~18dBm
RX sensitivity -85dBm
Operating
temperature
Max 50°C
Storage
temperature
-20°C ~ +60°C
Operating humidity <85%RH
Sensor type CMOS
Outdoor camera View angle About 85°
Supply voltage DC/AC 8~24V (battery:
3.7V/2000mAH 18650)
Consumption
current
300±50mA
Screen size 4,3 inch (diagonal)
Resolution 480x272(RGB)
Supply voltage DC 5V/1A (battery:
3.7V/1500mAH)
EN
