Instruction manual
9
3.3.6 Connecting a door lock (not included)
It is possible to connect a lock to the outdoor unit that can be opened,
using the monitor.Door locks are sold separately. Article no: DB5005
& DB5005L
To connect the door lock, you will need the following tool:
ü A small flat head screw driver.
A. On the outdoor unit: Loosen the terminal screws. (see sticker on
the outdoor unit for position)
B. Insert the wires (See sticker on the outdoor unit for position)
C. Fasten the terminal screws.
D. On the lock: Loosen the 2 terminal screws.
E. Insert the wires (any order)
F. Fasten the terminal screws.
3.3.7 Connecting a gate opener (not included)
It is possible to connect a gate opener to the outdoor unit that can be
opened using the indoor unit (monitor).
To connect the gate opener, you will need the following tool:
ü A small flat head screw driver.
A. On the outdoor unit: Loosen the terminal screws. (see sticker on
the outdoor unit for position)
B. Insert the wires. (see sticker on the outdoor unit for position)
ð It is important that the + and – wires are in the correct position.
A. Fasten the terminal screws.
B. On the gate opener: (See the manual provided with your gate
opener.)
3.3.8 Connecting the external antenna (not
included)
The internal antenna is sufficient in most cases but can be extended
using the external antenna.
4 Basic functions
4.1 CONTROL BUTTONS
1. Intercom / monitor button
2. Unlock buttons
3. Menu / OK button
4. Up button / photo or recorder button
5. Direction buttons (down, left and right)
6. Call button / pair button
4.2 SCREEN ICONS
1. Wi-Fi signal strength
2. SD card inserted
3. a) Outdoor unit powered by battery
b) Outdoor unit powered by power adapter
4. a) Video recording
b) Picture captured
5. a) Indoor unit powered by battery
b) Indoor unit powered by power adapter
6. Time and date
• Charge the battery immediately when the icon indicates a low
battery level.
EN
