1 CONSOLE local management port
PON port
attribute
Transmission distance
20KM
Port rate
Downstream: 2.5Gbps Upstream: 1.25Gbps
Wavelength
Forwarding: 1490nm Receiving: 1310nm
Interface type
SC/UPC
Fiber type
9/125μm SMF (Single Mode Fiber)
Light transmission
power
Class B+ +1.5～+5dBm
Class C+ +3～+7dBm
Receiving sensitivity
Class B+ -28dBm
Class C+ -30dBm
Saturation power
Class B+ -8dBm
Class C+ -12dBm
Network management method
Support CLI
、
SNMP
、
TELNET
、
SSH
、
WEB
Business capabilities
Support device log, device upgrade, device management, condition
monitoring, configuration management, and user management.
Layer 2 switching configuration management: Like port
management, VLAN, RSTP, IGMP, ACL, QOS and so on.
PON function configuration management: Like OLT authentication,
DBA template, service template, line template and so on.
Backplane Bandwidth
136G
Size
440mm(L)*391mm(W)*44mm(H)
Weight
4kg
Power supply
220VAC
AC: 90V～240V，47/63Hz
-48DC
DC:-36V～-72V
Maximum power
70W
Working
environment
Working temperature
0～50℃
Storage temperature
-40
～
85
℃
Relative humidity
5
～
90% (Non-condensing)
Concluding Remarks
Thanks for using products of Shenzhen C-Data Technology Co. Ltd.
Contact Information:
Company Address: Room 601, Floor 6, Building F, Songbai Road 1008, Sunshine Community，
Xili Street, Nanshan District, Shenzhen, China
Factory Address: 1
st
floor, Building B, Wentao Industrial Park, Yingrenshi Community,
Shiyan Avenue, Baoan District, Shenzhen, China
Telephone: 0755-26014509/26014710/26014711
Fax: 0755-26014506
Email: Marketing@cdatatec.com
Website: www.cdatatec.com
www.cdatatec.com.cn
