19-inch cabinet column and to fix the OLT device to the cabinet.
3.4 Port and Connection
The chapter describes the port and power supply connection situation in OLT system,
mainly include the following parts:

Uplink Port

PON Port Connection

Ground Cable Connection

Management Port Connection
Please carefully read the following introduction before connecting each port of OLT:
3.4.1 Uplink Port
3.4.1.1 Port Explanation
OLT offers eight GE electrical port, eight GE SFP optical port and two 10 Gigabit port
for uplink. Electrical port and optical port can combination at the sometime, you can use
direct-through, cross cable or fiber connection of the OLT and uplink equipment.
SFP module can be the optical module or the electrical module, and follow standards
below:
 1000Base-LX (Long wave length)
 1000Base-SX (Short wave length)
 10/100/1000Base-TX (Electrical port)
When use the single mode optical fiber, the maximum transmission distance can be up to
10-40km; when use the multimode fiber, the maximum transmission distance is less than
500 meters.
Gigabit Ethernet uplink port supports the duplex mode and flow control auto negotiation.
But need note that the maximum length of the optical fiber is related
with work mode of the optical fiber:
 Maximum length of 1000Base-LX fiber is depend on duplex mode
 Maximum length of 1000Base-SX fiber is the same in both full duplex and half duplex
mode
3.4.1.2 Port Connection
There are two kinds of uplink network connection:

Cable with RJ45 connectors at both sides

Cable with LC connector at both sides
Decide the port type of OLT according to the port type of the uplink device (Switch or
Route)
3.4.1.3 Method of Making Cable
If you use SFP optical module, cable specification: the optical cable with LC connector at
