P9
Route mode：ONT as a home gateway equipment, ONT IP address can be obtained
in three ways, which includes DHCP, Static IP Address and PPPoE. The IP address of the
device on the user side is obtained through the DHCP address pool of the ONT, or by
manually setting;
Bridge mode: broadband Internet access HGU itself does not obtain the IP address of
the upper equipment distribution, also can not set the static IP address manually, the HGU
is used as relay equipment, and does not process the data.The IP address of the user
side device (PC) at the LAN port of HGU obtains through the OLT upper server, and the
PC accesses the Internet via DHCP, PPPoE and static IP address respectively.
5.1 Route Mode Configuration
5.1.1 Configure PPPoE WAN Connection for Internet in Route Mode
1. Login ONU’s WEB, select Network->WAN->WAN Connection, and then there
are some parameters for us to configure as follows:
【IP Version】Select ‘Ipv4’; If there is Ipv6 in the network, we can select ‘Ipv4/Ipv6’.
【Type】Select“PPPoE”.
【Connection Name】Select “Create WAN Connection”.
【 Port Binding 】 Band the physical ports (LAN1-4 Port ) with PPPOE WAN
connection. Besides, if user want to use wifi function, must bind
any SSID with DHCP WAN connection, and turn on wireless wifi
function. When user configures wifi function, could refer to
WLAN configuration this chapter.
【Enable DHCP Server】check this option;Normally, Terminal , connected to the
HGU ONU, will get an IP address from the ONU’s IP pool.
Therefore, we need to check this option to get the IP address.
【Enable NAT】Check ‘NAT’ feature；NAT is mainly used for address translation
function of local network and external network. The default is
checked enable status. If you do not check this option, maybe you
can’t surf the internet.
