P13
5.1.3 Configure Static IP Address WAN Connection for Internet in Route Mode
1. Login ONU’s WEB, select Network->WAN->WAN Connection, and then there are
some parameters for us to configure as follows:
【IP Version】Select ‘Ipv4’; If there is Ipv6 in the network, we can select ‘Ipv4/Ipv6’.
【Type】Select ”Static”.
【Connection Name】Select “Create WAN Connection”.
【Port Binding】Band the physical ports (LAN1-4 Port ) with Static ip WAN connection.
Besides, if user want to use wifi function, must bind any SSID with
DHCP WAN connection, and turn on wireless wifi function. When
user configures wifi function, could refer to WLAN configuration this
chapter.
【Enable DHCP Server】 check this option；Normally, Terminal , connected to the
HGU ONU, will get an IP address from the ONU’s IP pool. Therefore, we need to
check this option to get the IP address.
