Instruction Booklet2-Series
6
FUNCTION OF PARTS：
TOP CONTROL PANEL
•Speed Dial Knob
The Rabbit means fast and Turtle is slow. By turning this you control total speed
transferred to thumb lever.
•Self Diagnostic Warning Lights
Flashing indicates problems within scooter.
See page 17 for more information.
•Battery Gauge
T
here are five yellow LED lights. When all LED are on, batteries are fully charged.
When only two lights are on, the batteries need to be recharged.
ADJACENT TO TOP CONTROL PANEL
•Thumb Lever
Pushing the right thumb lever moves scooter forward. Pushing the left thumb lever
moves scooter backward. (This can be reversed if required by local dealer.) Releasing
both, engage automatic brake. These are also your accelerator. The further you
depress them, the faster you go. (Subject to position of Rabbit/Turtle control).
AT BASE OF TILLER
•Ti
ller Angle Adjustment
Pushing downward on the handle to loose. Moving handle to left to adjust. Pushing
up to lock tiller at comfortable angle.
BELOW SEAT
•Seat Lock Knob
Turn seat lock knob counterclockwise to loose. Turn it clockwise to lock seat position.
•Seat Rotating Lever
By pulling lever upwards to rotate to different direction.
•Armrest width Adjustment Thumbscrews
Loosen the two thumbscrews to adjust arm width; tighten again to lock into desired
position.
•Legroom Adjuster
There are few holes on front and rear frame tube to adjust legroom. Pull the toggle
latch to loosen and insert the detent pin to locate position. Push toggle latch again
to lock.
REAR BODY
•Rear Compartment Cover
Open the compartment Cover to access on board charger.
•Anti-tip wheel
Helps keep scooter from tipping over.
•Free-Wheeling Lever
When lever is in N (Neutral) position, scooter can be moved without power.
When lever is in D (Drive) position, scooter can be driven. Normal position is D.
To Next Page
