1-Series Instruction Booklet
The time needed to recharge will vary depending on the depletion of the
batteries. Charging for longer than necessary will not harm the batteries.
They can not be overcharged.
9
CHARGING THE BATTERIES
Your C.T.M. scooter is equipped with two sealed, maintanence free 12V. 12Ah. rechargeable
batteries and one HS-115 24V/1.5A charger & HS-118 24V/1.8A charger. Batteries must
be charged before using scooter for first time and should be recharged after each day's
use. Be sure power switch is in OFF position and free-wheeling lever is not in freewheel
mode.
1.Insert battery charger cord into Charging Socket (K) on battery pack.
2.Plug other end of power cable into a standard electrical wall outlet.
3.The charging indicator (K) will normally be red or yellow at this point.
4.Allow batteries to charge until charging indicator turns green.
5.After indicator turns green, unplug battery charger from scooter and wall outlet.
6.If at any time battery charger light flashes green over 40 minutes, this indicates abnormal
charging occurred. You should check the following:
• Charger plug is correctly positioned
• Scooter is turned off
• If none of these are the problems, contact your local authorized dealer.
Figure 12
(K)
(K1)
