Instruction Booklet5-Series
Figure 1 - HS-588 / HS-589 Front View
Figure 2 -
HS-588/589 TOP CONTROL PANEL
Figure 3
HS-588/589 BACK VIEW
IDENTIFICATION OF PARTS
6
Before attempting to drive this scooter on your own, it is important that you familiarize
yourself with the controls and how they operate.
Anti-Tip Wheels
Storage Cover
Rear Turn
Signal and
Tail Lights
Free-
wheeling
Lever
Armrest Width
Adjustment
Thumbscrews
Optical Headlights
& Turn Signals
Front
Basket
Rearview Mirror
Tiller Angle Adjustment
Delta
Handle Bar
Mid-Back W/Headrest
Swivel Seat
Tilting Armrest
Seat Rotation Lever
Seat Sliding Lever
Side Reflectors
11" Front and
Rear Wheels
Self-Diagnostic Warning Light
Speed Control Knob
Hazard Light Button
Horn
Button
Left Turn
Signal Button
Headlight
Button
Right Turn
Signal Button
Throttle Control Lever
