C.T.M. HS-588 5 series User Manual

Instruction Booklet5-Series
12
DISASSEMBLING YOUR SCOOTER
Taking apart your scooter enables you to save space when keeping it in storage or to
carry it along in your vehicle when going away from home. Having the scooter disassembled
is easier than ever since no tools are required. Please follow these steps
Remove the seat by pull the Seat Rotation Lever (N) up and then lift off. (See Fig. 17)
Life up the Storage Cover (O). (See Fig. 18) and detach the Rear Lighting Wiring
Harnesses (P). (See Fig. 19) Remove the Rear Shroud (Q) gently which is held by
Ve
lcro.(See Fig. 20)
Figure 17
Figure 17
(N)
Figure 18
Figure 18
(O)
Figure 20
Figure 20
(Q)
Figure 19
Figure 19
(P)
