C.T.M. HS-928 Instruction Booklet

Instruction Booklet9-Series
Pull the lever (T) upwards to disengage and rotate seat (P) to required angle, Let go of
the lever (T) to lock the seat into its required position.
Seat Swivel Adjustment
Pull the lever (U) upwards to adjust backrest's angle, then release the lever when adjusted
to required position.
Seat Back Angle Adjustment
8
When driving the scooter, set the seat (P) at foremost position to prevent
tip over.
Pull the armrest up when get on or off the scooter.
Do not hang heavy parts on the armrests to cause tip over.
For safety reasons the backrest's position must remain vertical before driving.
Sit firmly on seat after getting on the scooter, do not stand on the foot rest
to prevent tipping over or damaging to the scooter.
Seat Fore-Aft Adjustment (P)
Pull the Seat fore-aft Adj Lever (Q) to disengage the seat (P). Slide the seat forwards or
backwards into the required position. Let go of the lever (Q) again to lock the seat into its
required position.
Angle Armrest Adjustment (R)
Pull the lever (S) and adjust the armrest to the required angle.
Figure 10
Figure 10
(R)
(S)
Figure 9
Figure 9
(P)
(Q)
Figure 12
Figure 12
(U)
Figure 11
Figure 11
(P)
(T)
