C.T.M. HS-928 Instruction Booklet

Instruction Booklet9-Series
9
1.Refer to page 13 for disassembly, then remove seat (P) and rear shroud (Z). (Figs 18 & 19)
2.Remove screw, nut and washer from seat post (V). (Fig 13)
3.Adjust seat post (V) to desired height, and attached tightly with screw, nut and washers. (Fig 13)
4.Then assemble the rear shroud (Z), seat (P) back to its original position. (Fig 18 & 19)
Seat (P) Height Adjustment
•Do not operate this function on a slope, or in motion or under unstable
condition.
•The main purpose of this function is to assist you to reach certain height.
•Seat's position must remain at the lowest before driving.
•Do not set N-D lever at N, before setting the seat at lowest position.
•Please keep the center of gravity of the scooter in the middle, to prevent
the scooter tipping over.
Freewheel operation is only recommended on flat surfaces, never on
gradients. Never leave your scooter on a gradient with its motors disengaged.
Always re-engage the motors immediately after pushing the scooter.
1.Press seat lifter button (W) lightly, seat will raise.
press lightly, seat will lower.
Seat (P) Electrical Lifter (Optional)
1.When scooter stopped or malfunction, press the unlocking knob on the N-D lever (X).
Push the N-D lever forwards this will allow you to push the scooter by hand.
N-D Lever Adjustment :
Figure 14
Figure 14
(V)
(P)
(W)
Figure 13
Figure 13
Figure 15
Figure 15
(X)
N
D
The scooter won't operate, if the
scooter is setting at N position,
to restore to it's normal status,
you must switch the power off
and adjust to D position, then
switch the power on.
(V)
Figure 13
Figure 13
